FLOWMON中等流量系列流量指示器流量开关流量计

流量范围对应型号：FM13/FM16/FM19/FM25/FM40/FM50/FM80/FM100

SPDT三线四线机械开关

DPDT六线机械开关

4-2mA输出

0-10v电位器

数字速率总计器

ATEX变体可用

单独校准到任何测量单位

范围内精度为 /- 3%

单尺度或双尺度

简单的模块化设计

低压降

粘度高达600cSt

开关设定点处重复性为1%

可安装在任何位置

防风雨外壳盒

能够两倍于指示的流量

应用

水, 可溶性油（甘油）,成基液体 ,腐蚀性液体,溶剂,

去离子水, 石油基液体, 冷却剂, 油漆, 空气与气体

flowrate Switches

• SPDT 3 & 4 wire mechanical switch (gold available)

• DPDT 6 wire mechanical switch

• 4-20mA Output

• 0-10v Potentiometer

• Digital Rate Totaliser

• ATEX variants available

• Individually calibrated to any unit of measure

• Accuracy +/- 3% across full scale

• Single or dual scale

• Simple modular design

• Low pressure drop

• Viscosities up to 600cSt

• 1% rate of repeatability at switch set point

• Installed in any position

• Weatherproof enclosure box

• Capable of twice the indicated flow

  Applications

  • Water

  • Soluble Oils (Glycols)

  • Synthetic Based Fluids

  • Corrosive Fluids

  • Solvents

  • De-ionised Water

  • Petroleum Based Fluids

  • Coolants

  • Paints

  • Air & Gases

    Flow range with model :

    FM13/FM16/FM19/FM25/FM40/FM50/FM80/FM100
